JHT focuses on the research and development and production of ultra-high performance concrete mixers, with vertical axis planetary mixers applied in the ultra-high performance concrete industry. Single motor drive, stable operation, quickly dispersing fibers to uniformity; Durable, efficient, and easy to maintain;
The improvement of tensile strength and toughness in ultra-high performance concrete mainly relies on the addition of steel fibers, which requires the material to ensure that steel fibers can be evenly distributed in cement-based materials during the preparation process. JHT ultra-high performance concrete mixer is a specialized mixer designed and developed for the production of ultra-high performance concrete, based on the technology of vertical axis planetary mixer and combined with the actual production conditions in the industry.
| Model | UHPC | 50 | 100 | 150 | 250 | 330 | 500 | 750 | 1000 | 1250 | 1500 | 2000 | 2500 | 3000 |
| Filling Volume | L | 75 | 150 | 225 | 375 | 500 | 750 | 1125 | 1500 | 1875 | 2250 | 3000 | 3750 | 4500 |
| Feeding Capacity | Kg | 120 | 240 | 360 | 600 | 790 | 1200 | 1800 | 2400 | 3000 | 3600 | 4800 | 6000 | 7200 |
| Output Volume | L | 50 | 100 | 150 | 250 | 330 | 500 | 750 | 1000 | 1250 | 1500 | 2000 | 2500 | 3000 |
| Mixing Power | Kw | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 30 | 37/45 | 45/55 | 55/75 | 75/90 | 90/110 | 110/132 |
| Mixing Star*Mixing Blade | Qty | 1*2 | 1*2 | 1*2 | 1*2 | 1*2 | 1*3 | 1*3 | 2*3 | 2*3 | 2*3 | 3*3 | 3*3 | 3*3 |
| Side Scraper/Discharge Scraper | Qty | 1/- | 1/- | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | 1/2 | 1/2 | 1/2 |
| Discharging Power | Kw | Pneumatic Discharging | 2.2 | 2.2 | 2.2 | 3 | 3 | 3 | 4 | 4 | 4 | |||
| Diameter | mm | 750 | 1000 | 1300 | 1300 | 1600 | 1900 | 2200 | 2500 | 2500 | 2800 | 3400 | 3400 | 3400 |
| Weight | Kg | 500 | 850 | 1300 | 1500 | 2200 | 2500 | 3500 | 5500 | 6000 | 6500 | 8500 | 10500 | 11000 |
High uniformity mixing effect
Planetary operation and high-speed auxiliary mixing make the mixing of ultra-high performance concrete more ideal.
Complex mixing curve, no dead corners, fully covered in 5 seconds.
It can evenly distribute fibers within the cementitious matrix in a short period of time, solving the problems of agglomeration and pushing during the mixing process.
Advanced and flexible design without leakage
Top mounted drive, mixing without slurry leakage.
The discharge door can be opened 1-3 times to meet the personalized usage needs of users.
The mixer is designed with a compact structure, simple maintenance, and high reliability.
- Strict production process
Raw material rust removal, laser cutting, one layer of primer, three layers of topcoat (or hot-dip galvanizing) - Durable and sturdy
The heavy-duty H-beam chassis reduces the impact of vibration symmetry during the production process. The batching machine and weighing hopper are made of 6mm steel plate, and the water and gas pipelines are made of galvanized pipes - 7 * 24-hour work
Excellent performance accessories are the guarantee for long-term operation of equipment: BHS or SICOMA concrete mixers, ABB or Marathon motors, WAM powder accessories, AIRTAC pneumatic components, Schneider Electric - Control system saves 50% -70% of operators
Control software can enable one computer to control two production lines or three production lines. By using Ethernet cables to transmit signals, remote operation and production can be achieved
1. Design your own concrete mixing plant based on site and functional requirements
2. For those with manufacturing capabilities, JHT can provide technical drawings (overall or partial); Reduce transportation and procurement costs
3. Renovation of old concrete mixing plants: will increase productivity by 10-20%.
JHT adopts decentralized shared production; Centralized procurement of supporting parts; We have achieved a low price, high-quality service system.
